Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
It fit just what i needed quick deliverey thank you
Arrived quick in good condition just what I needed it worked thank you
Guest - February 18, 2020
Verified Purchase
★★★★★
★★★★★
Drill press switch
Drill press switch broke this was a perfect replacement
Guest - February 22, 2020
Verified Purchase
★★★★★
★★★★★
Switch
Easy fix, perfect fit thanks
Guest - March 23, 2020
Verified Purchase
★★★★★
★★★★★
Drill press switch.
The switch I ordered came within a couple days and is the correct fit. This company is a must if you have equipment. You can find pretty much anything you need .
Guest - October 16, 2023
Verified Purchase
★★★★★
★★★★★
Good stuff
This switch fit the old saw just as the original and worked perfectly.
The slightest bug in the ointment was that this switch was built as a double pole and the original was single pole. An ohmmeter clarified the functionality.
Guest - March 13, 2024
Verified Purchase
★★★★★
★★★★★
Switch
The part arrived when promised and working fine.
Guest - June 18, 2024
Verified Purchase
★★★★★
★★★★★
Swich
Very
Smatisfid
Guest - May 28, 2025
Verified Purchase
★★★★★
★★★★★
Replacement switch
The switch is a perfect solution to replace my defective switch
Guest - September 22, 2025
Verified Purchase
★★★★★
★★★★★
Worked as advertised
The replacement part I ordered was exactly what I required to repair my Scroll Saw. Thanks to eReplacements Parts for having the part in stock and the very quick delivery. I had very little down time due to your expertise and quickness. Thank-You.
Guest - March 24, 2020
Verified Purchase
★★★★★
★★★★★
A direct replacement which made repair a simple task.
Fast shipping. A simple fix because it was a direct replacement part.
Guest - April 12, 2020
Verified Purchase
< Prev
1
2
3
Next >
Questions & Answers
?
Our customer Service team is at the ready daily to answer your part and product questions.
Be the first to ask our experts a question about this part!
Ask our Team
We have a dedicated staff with decades of collective experience in helping customers just like you purchase parts to repair their products.
Ask our experts a question on this part and we'll respond as soon as we can.
Something went wrong. Please try again later.
Your Question Has Been Submitted!
Our experts will send you an email as soon as your question has been answered.
Customer Repair Instructions
All our customer repair instructions are solicited directly from other customers just like you who have purchased and replaced this exact part.
Easy
15 - 30 mins
(100 rated repairs)?
< Prev
1
2
3
Next >
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
The on and off switch was broken, the table saw could not be turned off without unplugging. When you plugged it in the switch was always on even when you turned it to the off position.
I chose to remove the whole switch and the cords connected to the table saw so I could have an easy access. Then I removed the back of the switch and disconnected the cords plugged into the switch. I then removed the switch from the housing and inserted the new switch. I connected the wires, plugged the saw back in and tested the on and o
... Read moreff switch. This worked so I then reconnected the switch and electrical cord to the table saw. Great fix!
1. Removed the switch cover
2. Removed the wires from the back of the switch.
3. Used flat blade screwdriver to remove switch from saw.
The replacement switch had four terminals instead of the two that were on the original. However, there was a schematic on the side of the new switch that showed you what terminals to use
... Read more.
4. Snapped new switch into place.
5. Plugged wired onto new switch.
6. Re-installed switch cover.
1. Disconnect power source
2. Remove 4 switch cover plate screws.
3. Remove 2 power supply wires form back of switch by gently unplugging them
Note: polarity does not matter but try note position and place them on same terminal of new switch.
4. Remove old switch from cover plate by pressing in gently on side loc
... Read moreking clips and pulling switch free from plate.
5. Install new switch by pressing in from top side of plate until locking clips snap into place and switch is secure, attach wires and replace switch /plate assembly on machine.
6. Restore power and test operation.
1. Remove switch housing from table saw
2. Remove 3 screws on back of switch housing
3. Disconnect wires noting location on switch
4. Remove old switch
5. Install new switch
6. Remove red cover off paddle as will not work with new switch.
7. Connect wires.
8. Reassemble.
Removed switch hub and changed out with new switch. It took some manipulating to get the wires turned in the right directions. Got it wrong the first time and had to redo it. Second time worked fine.
Replaced motor,switch and power cord. First I installed the motor and felt as long as I was in there I would install a new switch and power cord. For me it was very easy repair. Easy ordering the parts and staff was very helpful
Did you find this story helpful?
Thank you for voting!
Table saw on/off switch broke while the saw was on, had to unplug the power cord to shut off.
1. Removed the rear switch cover.
2. Took a photo of the 4 wires plus the 2 ground wires to assure the wires would be reattached properly.
3. Unhooked the wires.
4.Removed the swich and installed the new switch.
5. Reattached the wires.
6. Replaced the rear cover switch.
Did you find this story helpful?
Thank you for voting!
Cutter head stopped turning and unit would not turn on.
1. Unplugged unit from power.
2. Remover 4 screws holding switch cover.
3. Removed switch from cover and snapped in new switch.
4. Removed wires from old switch and connected to new switch.
5. Installed switch and secured with the screws.
6. Removed brush covers and removed old brushes.
7. Inserted ne
... Read morew brushes and replaced brush covers.
8. Removed old blades and installed new blades.
Read less
Did you find this story helpful?
Thank you for voting!
On off switch failed and I broke the switch box thus ordered box and switch, easy repair and cheap.
Removed the broken switch box, then removed the on off switch from it. Removed the wires from the old switch to then new one. Then installed the new switch and the switch box.
1. Removed red, plastic, quick shut off flap by prying the two pivot flanges out from the pins on which it swivels with a screw driver - hoping that I wasn\'t going to break off one of the flanges causing me to spend another $38 on another little piece of plastic.
2. Removed the two machine screws from the plastic frame that holds t
... Read morehe switch in place and pulled the switch and frame and attached 4 wires out from the body of the planer. Not much extra wire to play with so I marked the wires and pulled them free from the metal tabs on the back of the broken switch. I was now able to separate the old switch from the frame (had to break the small plastic pieces on the back of the old switch which held the switch to the frame).
3. Inserted the new switch into the frame.
4. attached the wires to the proper tabs as I had marked.
5. Pushed the frame and switch back into the body of the planer and reinserted the two screws holding the frame to the body of the planer
6. All worked well after
Read less
Did you find this story helpful?
Thank you for voting!
< Prev
1
2
3
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP10325609
Manufacturer Part Number: 489105-00
