This high-quality spindle and pulley assembly is a genuine OEM replacement part, specifically designed for use with riding lawn mowers and lawn tractors. Built from durable metal components, it serves as the mounting point for the mower blade and the deck belt that drives it.
Depending on your mower model, your deck may require two or three of these assemblies.
Note: The spindle housing features non-threaded mounting holes. Be sure to use self-tapping bolts to secure the housing to the deck.
This item is sold individually. For proper fit and installation, refer to your equipment’s model diagram.
1. Removed deck from lawn tractor by taking off associated cotter pins.
2. Removed broken spindle pulley.
3. Replaced with new spindle pulley.
4. Replaced adjustment gear.
5. Replaced deck by inserting cotter pins into the associated connections.
Did you find this story helpful?
Thank you for voting!
Blade spindles failed causing belt and brake pad failure also.
1. Removed mower deck from lawnmower.
2. Removed both old mower blade assemblies, both old brake pad assemblies and old blade drive belt.
3. Installed both new mower blade assemblies, both new brake pad assemblies and new blade drive belt.
4. Both mower blades were sharpen and balanced before they were installed o
... Read moren mower deck assy.
5. Installed mower deck assy. back on lawnmower.
Put the mower up on blocks, removed the blades, and removed and replaced the Spindle assembly. Before putting on the new spindle assembly, replaced the brake deck assembly. Put on new blades. Works great.
removed mower deck (hardest part of repair) , used wood block to jam and remove blade, removed broken spindle, new spindel bolted in place (4 self tapping bolts),noticed other spindle about to go out, ordered replacement, replaced 2sd spindle, made sure belt was routed correctly, replaced mower deck.
1. Removed lawn deck
2. Removed old spindles and blades.
3. Set taps for original screw size on new spindles.
4. Installed new spindles on deck.
5. Replaced old blades with new mulching blades.
6. Reinstalled the mower deck to tractor.
Did you find this story helpful?
Thank you for voting!
the mounting holes were not taped out to bolt to the deck
