This is an Authentic OEM sourced replacement part designed for use with Husqvarna Chainsaws. This is the Hose that delivers fuel from the Tank to the Engine. It is made out of Rubber and it is Sold Individually. Please note Fuel Filter is Sold Separately.
Drained fuel. Took old fuel hose out.removed fuel filter, replaced filter on new hose. Removed other end from carburetor. Put on new fuel hose in..(a little tough) but chainsaw works flawlessly now. I have a Husqvarna 345.
1. Remove chain and bar( for easy maneuverability), empty gas in tank, then top cover, followed by handle and throttle grip. The throttle has to be disconnected from carb, and you have to spin the linkage to remove because it does not come straight out.
2. You can choose to remove carb, I was able to do repair without removing, prob
... Read moreably more difficult, but might have saved a little time. I removed return line and fuel lines and prime bulb from saw, followed by grommets. To remove fuel line you have to open gas tank and pull out filter and fuel line with your 90 degree pick. Remove filter and hose, replace with new.
3. When I replaced grommets and hose, I put a little oil on them to make things go on a little easier. I found it is easier to install grommets on hose first and then install grommets on saw. You can always push and pull hose through.
4. Once all hoses are on and secure, reinstall your filter on line and replace inside tank. I cut about two inches off the tank line before installing filter, just because it seemed a little long, your choice. I only had one line that was bad, but I figured while I was replacing one, might as well do them all, the others are probably going to fail soon.
5. In order to replace exhaust screen, you will have to remove chain break handle, two hex head bolts, slide screen out, slide new one in and done.
6. Once installed, I reassembled everything in the reverse order it come out. Chain brake handle, main handle then throttle cover, remember to install throttle linkage, you have to spin it to get back next to the carb, this can be a little tedious, but make sure it is where it needs to go before bolting main handle on, or you have to take it apart again(my mistake).
7. After throttle cover, replace your top cover, and chain and bar, add gas and your good to go.
Replaced the primer bulb (air purge), and the fuel line from the carburetor to the tank. Have to remove the cylinder cover and air filter to access fuel lines. Getting the new fuel line into the tank beside the carburetor is the most difficult part. The fuel line is spiraled, or coiled from the factory and is this way on purpose so it
... Read morecan flop back and forth inside the tank regardless of what position the chainsaw is held. This creates a bit of an issue getting the fuel line into the small bushing it goes thru in the tank. A little ingenuity and patience will get it done. I used the hemostats and a very long piece of wire to pull the fuel line thru into the tank. The hemostats also helped out greatly getting the new fuel line in place on the nipple on the carburetor because the throttle linkage does not leave enough room for fingers.
It went well , the old Gas line originally made from transparent flexible plastic was 50 thousand of an inched smaller than the replacement line purchased , the new one was made of rubber meaning that it had a better seal as it went trough the gas tanks , this one being 50 thousand larger than the original provided a better seal so I did
... Read morenot lost pressure in the tank meaning the saw no longer starved for gas .
I am very satisfy with the result.
Pete
Read less
Did you find this story helpful?
Thank you for voting!
Wear and tear, leaking bar oil, fuel lined cracked and running lean,
Removed saw from handles and frame, disassembled the carburetor and throttle linkage. Replaced fuel filter and gromment along with the bad fuel line and reassembled.
Replaced plug, fuel hose,filter and air filter .the fuel hose was the hardest part (that took maybe 5 min.) all parts fit perfect.so with with cleaning up my tools and wiping up my spilled coffee, this job took maybe 30 minutes thanks .. ereplacementparts again hope to see you soon......Arty........
Took top of saw apart to get to the opening where the fuel line goes from the carb to the tank. installed new hose and original fuel filter. Installed straight hose. Put the saw back together. Runs fine after repair.
Did you find this story helpful?
Thank you for voting!
< Prev
1
2
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP16380211
Manufacturer Part Number: 591375201
Chainsaw
- Husqvarna Chainsaw Model 3120XPEPA Parts
✖
Stock Status
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
New stock is on the way! On order parts usually ship within 7 business days.
Item is not in stock and usually ships 10-15 business days from the time you place your order.
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
✖
Mail-In Recycling Rebate
Some of the parts we sell are eligible for mail-in rebates since we can recycle them. We will display any applicable rebates in your shopping cart. To redeem your rebate, contact Customer Service after you have received your part.
✖
