Remove blower housing 4 bolts, remove primer cover, pinch gas line, remove carb 2 nuts...heat shield and gasket will come off too. Undo hose clips and remove gas line and primer hose from carb. Remove gas tank by undoing 3 nuts..two on carb side one on far side. Undo pinching of gas line. Drain gas in a coffee can. Unscrew gas line from t
... Read moreank..undo hose clamps.
Reassemble with new fuel line kit and new carb. Don\'t waste time with carb cleaning kits. New carb kit was around 30 dollars. Entire job was less than an hour.
Toro Power Clear 180.
Note if you live in area with reformulated gas...a lot of areas in Midwest...change these parts after a few years. The gas is real hard on the gas delivery system.
1) Removed plastic cowling to gain access to carburetor
2) Removed fuel tank
3) Removed and replaced all fuel filters and fuel lines
4) Removed carburetor and replaced with new carburetor and gaskets
5) Highly recommend to take pictures of old carburetor with linkages connected before replacing with new for refe
... Read morerence
6) Put in new fuel-it started on the second pull
Read less
Did you find this story helpful?
Thank you for voting!
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP9884431
Manufacturer Part Number: 121-0487
Snow Blower
- Toro Snowblower Model 38283/SERIAL: 312000001-312999999 (38283/SERIAL:312000001312999999, 38283/SERIAL: 312000001 312999999) Parts
✖
Stock Status
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
New stock is on the way! On order parts usually ship within 7 business days.
Item is not in stock and usually ships 10-15 business days from the time you place your order.
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
✖
Mail-In Recycling Rebate
Some of the parts we sell are eligible for mail-in rebates since we can recycle them. We will display any applicable rebates in your shopping cart. To redeem your rebate, contact Customer Service after you have received your part.
✖
