9003033-1-M-Ariens-52423100-Gearcase- Cast Iron 28-inch
Part Location Diagram of 52423100 Ariens Gearcase- Cast Iron 28-inch
See part F-800 in the diagram
( Grid squares measure 1x1 inch )
9003033-1-S-Ariens-52423100-Gearcase- Cast Iron 28-inch Part Location Diagram of 52423100 Ariens Gearcase- Cast Iron 28-inch

Gearcase- Cast Iron 28-inch 52423100

Manufactured by:
Ariens
ERP Number:
ERP9003033
Part Number:
52423100
Original Equipment Manufacturer ?
$636.78
Special Order

A Bit Difficult

More than 2 hours

(1 rated repair) ?

Does this part fit my model?

Need help finding your model number?

Jump to:

Troubleshooting Repair Instructions Model Cross Reference

Troubleshooting

This part works with the following brands:
  • Ariens
This part works with the following products:
  • Snow Blower

Customer Repair Instructions

All our customer repair instructions are solicited directly from other customers just like you who have purchased and replaced this exact part.

A Bit Difficult

More than 2 hours

(1 rated repair) ?
  • 1
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.

Snow blower auger worm gear failure. The shear pin did not break properly.

C from South Lake Tahoe, California

3 of 3 people found this instruction helpful.
Difficulty Level:
A Bit Difficult
Total Repair Time:
More than 2 hours
Tools:
Pliers, Socket set, Wrench set
Parts Used:
52423100
Had to buy an assembly because you can\'t buy just the worm gear for this blower anymore. Disassembly was easy except the impeller was rusted to the shaft. I had to cut the shaft, drill out a bore hole, and pound the rest of the shaft from the impeller. It would be an easy fix if you were to buy an impeller and the assembly, however I did n\'t want to spend the extra money on the impeller. Other than that it is an easy repair. You will also need a new woodruff key and roll pins.
Read less
Did you find this story helpful?
Thank you for voting!
  • 1

Model Cross Reference

This part works with the following models:
ERP Number: ERP9003033
Manufacturer Part Number: 52423100
Brand Model Number Description
Ariens 924108 Snow Blower - ST824 SLE 8hp Electric 24" Snowblower
Ariens 924109 Snow Blower - ST1028 SLE 10hp Electric 28" Snowblower
Ariens 924110 Snow Blower - ST824 DLE 8hp Electric 24" Snowblower
Ariens 924116 Snow Blower - ST1028 10hp 28" Snowblower
Ariens 924118 Snow Blower - ST8524 DLE 8.5hp Electric 24" Snowblower
Ariens 924119 Snow Blower - ST1028 10hp 28" Snowblower
Ariens 924121 Snow Blower - ST1128 LE 11hp Electric 28" Snowblower
Ariens 924324 Snow Blower - ST1128LE 11hp Electric 28" Snowblower
Ariens 924328 Snow Blower - ST824 DLE 8hp Electric 24" Snowblower
Ariens 924329 Snow Blower - ST928 LE 9hp Electric 28" Snowblower
Ariens 924551 Snow Blower - ST8524 DLE Classic 8.5hp Electric 24" Snowblower
