Bosch colt repair
If your Bosch colt router needs a new lower bearing this is the place. Good price, fast shipping, and it's only a 10 minute repair job. Thanks.
Guest - August 12, 2019
Verified Purchase
★★★★★
★★★★★
Perfect fit
The right part and it arrived on time. My router is like new. Much better for the pocketbook and environment than just throwing this router out and buying a new one.
Guest - January 13, 2023
Verified Purchase
★★★★★
★★★★★
Perfect replacement part for my GKF-125 Bosch router
Putting in this new bearing has eliminated the wobble of the bit when using the router in my CNC machine. Once I figured out how to get the old bearing out and the new bearing in to the router, the repair was relatively easy.
Robert - July 14, 2023
Verified Purchase
Customer Repair Instructions
All our customer repair instructions are solicited directly from other customers just like you who have purchased and replaced this exact part.
A Bit Difficult
30 - 60 mins
(5 rated repairs)?
< Prev
1
Next >
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Bearing spun in the bearing flange and caused it to be loose
Disassembled the router per the detail parts list on your website. Start by removing the brushes and then separate the armature from the lower bearing housing (collet end). The upper bearing appeared to be a press fit so I used a gear puller to remove this item. Having some wood blocks and a vise greatly helps holding the armature duri
... Read moreng the bearing removal and replacement process. I did not clean the commutator as I did now want to risk damaging any surfaces or windings. Take pictures as you disassemble as there are a few small parts such as small spring washers that can get misplaced during the process. After the bearings are installed reassemble in reverse order from disassembly and the final step is replacing the brushes. Take note of the brush spring to be sure it rides freely in the brush holder before replacing the brush caps.
1)Removed bearing nut.
2) Removed housing screws.
3) Removed locking mechanism from old housing and installed on new housing, replaced old cap with new cap.
4) Pulled brushes and removed armature.
5) Used puller to remove upper bearing and bearing driver to install new bearing.
6) Installed armature.
7)
... Read more Installed new housing assembly.
8) Tightened down bearing nut.
9) Installed brushes.
10) Celebrated victory!
I disassembled the router but I also destroyed another part while breaking it down. So I decided instead of ordering the other part for over $30. I decided to buy a new Bosch Colt hand held router. I plan to do that in the next couple of weeks. A new colt will be about $100. thanks for having the parts and making them available.
Did you find this story helpful?
Thank you for voting!
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP19509896
Manufacturer Part Number: 2609110435
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
New stock is on the way! On order parts usually ship within 7 business days.
Item is not in stock and usually ships 10-15 business days from the time you place your order.
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
✖
Mail-In Recycling Rebate
Some of the parts we sell are eligible for mail-in rebates since we can recycle them. We will display any applicable rebates in your shopping cart. To redeem your rebate, contact Customer Service after you have received your part.
