10124567-1-M-Milwaukee-28-28-1000-Diaphragm
Part Location Diagram of 28-28-1000 Milwaukee Diaphragm
See part 33 in the diagram
( Grid squares measure 1x1 inch )
10124567-1-S-Milwaukee-28-28-1000-Diaphragm Part Location Diagram of 28-28-1000 Milwaukee Diaphragm

Diaphragm 28-28-1000

Manufactured by:
Milwaukee
ERP Number:
ERP10124567
Part Number:
28-28-1000
Original Equipment Manufacturer ?
$7.59
Special Order

Does this part fit my model?

Need help finding your model number?

Jump to:

Description Troubleshooting Model Cross Reference

Product Description

?

This is an original Milwaukee replacement part. The diaphragm is designed by the manufacturer for use in Sawzalls. This part is made of metal, and is placed in the machine to help secure the armature and the wobble shaft axle. You will require a screwdriver when replacing this item. This part is sold individually.

Troubleshooting

This part works with the following brands:
  • Milwaukee
This part works with the following products:
  • Reciprocating Saw

Model Cross Reference

This part works with the following models:
ERP Number: ERP10124567
Manufacturer Part Number: 28-28-1000
Brand Model Number Description
Milwaukee 6509-20 Reciprocating Saw - Sawzall
Milwaukee 6509-22 Reciprocating Saw - Sawzall
Milwaukee 6509-68 Saw - Milwaukee 6509-68-(00010705) Parts
Milwaukee 6519-22 Reciprocating Saw - Sawzall
Diaphragm
$ 7.59
Special Order
✖
