Part Location Diagram of 31-1048-B GE WIRING DIAGR
See part 32767 in the diagram

WIRING DIAGR 31-1048-B

Manufactured by:
GE
ERP Number:
ERP722138
Part Number:
31-1048-B
Original Equipment Manufacturer ?
$41.56
Special Order

Does this part fit my model?

Need help finding your model number?

Troubleshooting

This part works with the following brands:
  • General Electric
  • Hotpoint
This part works with the following products:
  • Range
Part# 31-1048-B replaces these:
031-1048-B,

Model Cross Reference

This part works with the following models:
ERP Number: ERP722138
Manufacturer Part Number: 31-1048-B
Brand Model Number Description
General Electric JBS02*R1 Range - Electric
General Electric JBS06*R1 Range - Electric
General Electric JBS06*R2 Range - Electric
General Electric JBS06G*R1 Range - Electric
General Electric JBS06G*R2 Range - Electric
Hotpoint RB524*R1 Range - Freestanding, Electric
Hotpoint RB525*R1 Range - Electric
Hotpoint RB525G*R1 Range - Freestanding, Electric
