Genuine Dewalt replacement part This brush is sold individually, 2 are needed for the tools shown below It is always best to replace both brushes, even if only one is worn. Worn brushes frequently are the cause behind a motor running poorly. Replacing brushes can fix a motor that's operating intermittently. New brushes can restore a motor's electric braking. Carbon brushes are one of the most commonly replaced power tool parts. This is because carbon brushes are wear items, meaning that through friction and use they will gradually wear away until they need replacing. Worn brushes are a common causes of intermittent motor function, reduced electric braking and reduced motor power. A worn-out brush will often be worn down near to the wire lead and can be cracked, pitted, or burned. When replacing carbon brushes, be sure to inspect your armature for burns, cracks, or other damage which can indicate larger motor problems.
Replaced brushes, $12.00 + 15 min. work restored $1000. saw to perfect operation. Proper P.M. would save a lot of power tools from being ruined and scraped. All you need to do is use a screwdriver to remove the brush caps. Then remove the old brushes and install the new ones, then just replace the brush caps. Your done.
1. Unplugged the saw from the outlet.
2. Unscrewed the brush cover screws.
3. Removed the old brushes.
4. Installed the new ones.
5. Screwed the covers back on.
6. Plugged back in.
Replaced the carbon brushes in 5 minutes. Take out the bush housing screws on the front and back of the motor remove old brushes put in new ones your done.
took off end cap, unscrewed the brush caps and changed them out. Simple install and great working part. This is the 2nd time I have done this repair as well as the brake/trigger switch. We use this saw 8 hours a day 5 days a week so they burn up rather quickly.
Did you find this story helpful?
Thank you for voting!
The switch worked when it wanted to. It was also shooting sparks from the brushes.
1. I removed the handle cover.
2. I unplugged the switch & removed it. There was one screw holding it in.
3. I plugged the new one in & secured it.
4. I put the handle cover back on.
5. The brushes each had a cover that needed to be remove from the motor end of the saw.
6. Then they both have a small r
... Read moreound cover that is removed with a flat head screwdriver.
7. The brushes slid right out & the new ones slid right in.
8. I put the brush covers & motor cover back on.
9. I plugged it back in & tested it.
10. Done.
Read less
Did you find this story helpful?
Thank you for voting!
< Prev
1
2
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP10181643
Manufacturer Part Number: 614367-00
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
