Part Location Diagram of 1-803022 Toro Screw-Set
See part F-21 in the diagram
( Grid squares measure 1x1 inch )

Screw-Set 1-803022

Manufactured by:
Toro
ERP Number:
ERP8815534
Part Number:
1-803022
Original Equipment Manufacturer ?
  Works with your model  LAS28KA724B!
$5.95
Special Order
  Works with your model   LAS28KA724B!

Troubleshooting

This part works with the following brands:
  • Exmark
  • Toro
This part works with the following products:
  • Lawn Mower
  • Lawn Tractor
  • Lawn Tractor Accessories
  • Cement Mixer
Part# 1-803022 replaces these:
1-803022,

Questions & Answers

?

Our customer Service team is at the ready daily to answer your part and product questions.

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

Ask our Team

We have a dedicated staff with decades of collective experience in helping customers just like you purchase parts to repair their products.

Does this fit my product?

Model Cross Reference

This part works with the following models:
ERP Number: ERP8815534
Manufacturer Part Number: 1-803022
Brand Model Number Description
Toro 110-3944 Chainsaw - Replacement Pulley Kit, Z593-d Z Master Models 74264 And 74265
Toro 110-3945 Chainsaw - Replacement Pulley Kit, Z593-d Z Master Models 74264te And 74265te
Toro 30524 Lawn Mower - Mid-size Mower, Proline Pistol Grip Hydro 15 Hp W/ 36-in. Sd Mower, 2002
Toro 30526 Lawn Mower - Mid-size Mower, Proline Pistol Grip Hydro 15 Hp W/ 48-in. Sd Mower, 2002
Toro 30527 Lawn Mower - Mid-size Mower, Proline Pistol Grip Hydro 15 Hp W/ 36-in. Sd Mower, 2003
Toro 30528 Lawn Mower - Mid-size Mower, Proline Pistol Grip Hydro 15 Hp W/ 48-in. Sd Mower, 2003
Toro 30801 Chainsaw - Hydraulic And Electrical Mounting Kit For High Lift Collection Groundsmaster 360 4-Wheel Drive Multi-Purpose Machine With Kubota Engine
Toro 30898 Chainsaw - Hydraulic And Electrical Mounting Kit For High Lift Collection Groundsmaster 360 4-Wheel Drive Multi-Purpose Machine With Yanmar Engine 2016
Toro 30984 Lawn Mower - Commercial Walk-behind Mower, Fixed Deck Pistol Grip Hydro With 36in Turbo Force Cutting Unit, 2006
Toro 30986 Lawn Mower - Commercial Walk-behind Mower, Fixed Deck Pistol Grip Hydro With 40in Turbo Force Cutting Unit, 2006
Toro 30988 Lawn Mower - Commercial Walk-behind Mower, Fixed Deck Pistol Grip Hydro With 48in Turbo Force Cutting Unit, 2006
Toro 30989 Lawn Mower - Commercial Walk-behind Mower, Fixed Deck Pistol Grip Hydro With 52in Turbo Force Cutting Unit, 2006
Exmark 32-125K-5 Lawn Mower - 32", 36", 48" Walk-Behind Mower, 12.5hp Kohler
Exmark 32-85B-5 Lawn Mower - 32", 36", 48" Walk-Behind Mower, 8.5hp Briggs And Stratton
Toro 39984 Lawn Mower - Commercial Walk-Behind Mower, Fixed Deck, Pistol Grip, Hydro Drive With 36in Turbo Force Cutting Unit.
Toro 39988 Lawn Mower - Commercial Walk-behind Mower, Fixed Deck, Pistol Grip, Hydro Drive With 48in Turbo Force Cutting Unit, 2008
Toro 60212 Cement Mixer - Mmx-650e-S Mortar Mixer
Toro 60213 Cement Mixer - Mmx-655h-S Mortar Mixer
Toro 60216 Cement Mixer - Mmx-658h-S Mortar Mixer
Toro 60216C Cement Mixer - Mmx-658h-S Mortar Mixer
Toro 60217 Cement Mixer - Mmx-658h-P Mortar Mixer
Toro 60219 Cement Mixer - Mmx-850e-S Mortar Mixer
Toro 60220 Cement Mixer - Mmx-858h-S Mortar Mixer
Toro 60220C Cement Mixer - Mmx-858h-S Mortar Mixer
Toro 60221 Cement Mixer - Mmx-858h-P Mortar Mixer
Toro 60221HD Cement Mixer - Mmx-858h-P Mortar Mixer
Toro 72264TE Lawn Mower - Z Master Professional 7000 Series Riding Mower, With 132cm Turbo Force Side Discharge Mower.
Toro 72265TE Lawn Mower - Z Master Professional 7000 Series Riding Mower, With 152cm Turbo Force Side Discharge Mower.
Toro 72266 Lawn Mower - Z Master Professional 7000 Series Riding Mower, With 52in Turbo Force Side Discharge Mower.
Toro 72267 Lawn Mower - Z Master Professional 7000 Series Riding Mower, With 60in Turbo Force Side Discharge Mower.
