1. Removed remaining pieces of ash sweep system and cut off bolt assembly with dremel.
2. Tapped out remaining chunk of rusted sweeper.
3. Cleaned up kettle of ash and carbon deposits
4. Installed new ash sweeps (no tools needed)
5. Added a One-Touch Gold ash pan
6. Measured to find center of kettle for
... Read more lid lock support, marked with pen
7. Measured to find mid points of kettle for lid bale. Lid wire holes should be 4\" from top of kettle bottom.
8. Drilled holes for lid wire bale and lock.
9. Inserted lid lock and wire bale.
10. Regular Weber 18.5\" grill converted to a lockable carry version.
1. Removed the Cook and Charcoal grate
2. Unscrewed the wingnut on the appropriate leg position.
3. Removed leg screw and washers.
4. Fed the screw thru the lid bracket and bowl
5. Tightened up the screw with the wingnut and screw driver.
6. Re-installed Grates.
For the record, it took longer t
... Read moreo write this review than it did do to the repair. It took less than 5 minutes
Read less
Did you find this story helpful?
Thank you for voting!
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP10512460
Manufacturer Part Number: 86821
Grill
- Smokey Joe Gold/Platinum/Tuck-N-Carry Grill
✖
Stock Status
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
New stock is on the way! On order parts usually ship within 7 business days.
Item is not in stock and usually ships 10-15 business days from the time you place your order.
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
✖
Mail-In Recycling Rebate
Some of the parts we sell are eligible for mail-in rebates since we can recycle them. We will display any applicable rebates in your shopping cart. To redeem your rebate, contact Customer Service after you have received your part.
![10512460-1-M-Weber-86821-Lid Lock Support, 18.5"](https://ereplacementpartscom-cbgkc7gwbuakdcd6.z01.azurefd.net/assets/partimages/10512460_1_L.jpg "10512460-1-M-Weber-86821-Lid Lock Support, 18.5"")
![10512460-1-S-Weber-86821-Lid Lock Support, 18.5"](https://ereplacementpartscom-cbgkc7gwbuakdcd6.z01.azurefd.net//assets/partimages/10512460_1_L.jpg "10512460-1-S-Weber-86821-Lid Lock Support, 18.5"")
