Genuine DeWalt replacement part. rnIncludes 1 Carbon Brush with wire lead and terminal in rubber sheath attached.rnrn • Worn brushes are frequently the cause of a poorly running motor. • Replacing brushes can fix an intermittently operating motor. • New brushes can restore a motor's electric braking. Carbon motor brushes are one of the most commonly replaced power tool parts. The reason is that carbon brushes are wear items, meaning that through friction and use they will gradually wear away and eventually will need replacing. Worn brushes are a common causes of intermittent motor function, reduced electric braking and reduced motor power. A worn-out brush will often be worn down near to the wire lead and can be cracked, pitted, or burned. When replacing carbon brushes, also check your armature for burns, cracks, or other damage which are indications of a larger motor problem needing attention.
Troubleshooting
This part works with the following brands:
DeWALT
Black and Decker
This part works with the following products:
Circular Saw
Reciprocating Saw
Trimmer
Part# 387558-01 replaces these:
387558-01
★
Customer Part Reviews
?
5.0
Average Rating (out of 5):
★★★★★
★★★★★
(5 Reviews)
Click to filter by ratings:
5 stars
5
4 stars
0
3 stars
0
2 stars
0
1 star
0
< Prev
1
Next >
Sort by:
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
Perfect replacement part, worked
OE like part that worked great.
Guest - May 14, 2019
Verified Purchase
★★★★★
★★★★★
Correct part, good quality
Arrived as promised
Guest - August 6, 2019
Verified Purchase
★★★★★
★★★★★
ok
ok
Guest - August 30, 2019
Verified Purchase
★★★★★
★★★★★
great part
Great part didn’t fix my problem hopeing new switch will do it.
Guest - May 26, 2020
Verified Purchase
★★★★★
★★★★★
Worked great and did exactly what I hoped it would do
part was packaged and labeled nicely. Saw-z-all is working perfect again. Thank you.
Guest - December 15, 2020
Verified Purchase
Questions & Answers
?
Our customer Service team is at the ready daily to answer your part and product questions.
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Ask our Team
We have a dedicated staff with decades of collective experience in helping customers just like you purchase parts to repair their products.
Remove the screws as the new clamshell doesn\'t come with screws. Which is ok. Didn\'t replace the brushes, after years of use, the originals were just slightly worn. Took care in routing wires from the switch through the new handle ( clamshell) and screwed the 2 halves together. Removed the foot and rubber cover and replaced the blad
... Read moree locking lever. Very easy.
Read less
Did you find this story helpful?
Thank you for voting!
Handle broke and one of the leads came off one of the brushes.
Removed old handle by taking out the screws separating the halves. Remove brushes by pulling back the spring metal that holds them in . With the spring metal held back slide your new brush in then let the spring metal push against the end of the brush to hold it in with it\'s spring tension. There is a positive and negative brush make sur
... Read moree you plug them in correct. There is a plus indicator mark for the positive side you will be able to see it. Then put both halves together and tighten screws. Do over tighten because it is only plastic
1. Took the broken handle apart saving the trigger switch and safety lock.
2. Remove the old brushes and wires. Hardest part of the whole job is moving the brush springs to the sides to remove the brushes.
3. Install the new brushes and wires
4. Place the trigger switch and safety lock in the new shell.
5. Pl
... Read moreace the new shell around the existing motor housing and install screws.
6. Check for proper operation.
Complete
Removed all case screws take apart to access interior motor. Remove old brushes replace with new. Broke brush ring in process that\'s why needed to replace that part, also very happy with ordering new parts and timely delivery to my home. thank you
Did you find this story helpful?
Thank you for voting!
Reciprocating saw was making bad noises, and jumping gears.
Had to take entire case apart. So you know, the nut on the bottom of the gear shaft is a left handed thread. Removed the nut, then the gear and shaft. This all tied into the mechanism that operates the blade shaft up & down. Kind of tricky getting them apart at first, but did come apart nice. Line the shaft and the mechanism back up, lock
... Read more together and slide shaft & gear back into place. Reinstall the nut, (lefty threads) and put case back together. Not too bad of a job, took approx. 10 - 15 minutes. Make sure to pick through the gear grease in the case, while apart. I found quite a few gear teeth mixed in with the grease, from the old gear. I got all the old junk out, and then added some new grease prior to reassembly.
Also... I had to put circular saw in the \"tool type\" because it \"did not\" have a reciprocating saw as an option. Maybe \"R.P.\" should add that as an option!
I took the still apart and realize that the brushes have welded themselves to the brush casing. As I tried to remove the brush it cracked the brush housing. I then ordered new brushes new springs and the brush holder and installed everything after carefully brushing down all the parts and cleaning everything. Put it all together and it wo
... Read morerks fine
Removed old brush. Added new terminal to brush feed wire added heat shrink to cover melted insulation, installed new brush and reconnected. Reassembled tool with torn screws.
Removed the clamshell and all the screws.
Install new Brush ring. Remove brush springs from old brush ring and install on new brush ring. Install new brushes. Reassembly clamshell case.
Replaced clam shell and (1) brush.
Simple remove all screws with a T10 Torx driver.
Reuse switch. Installed brush. ( Attached wire on brush was broken when handle failed.)
Replace with new parts. SIMPLE
Did you find this story helpful?
Thank you for voting!
Handle broke off a saws all and pulled already away from the brush
