Part Location Diagram of 544047101 Husqvarna Ignition Module
See part H-34 in the diagram
( Grid squares measure 1x1 inch )

Ignition Module 544047101

Manufactured by:
Husqvarna
ERP Number:
ERP9029862
Part Number:
544047101
Original Equipment Manufacturer ?
$118.75
In Stock
Delivers in 3-5 Business Days!

Easy

15 - 30 mins

(1 rated repair) ?

Does this part fit my model?

Need help finding your model number?

Product Description

?

This is an authentic Husqvarna replacement part, sourced from the original manufacturer for use with chainsaws. When the magnet on the flywheel passes the ignition module. The electric charge is sent to the spark plug to ignite the fuel/air mixture inside the combustion chamber.

Troubleshooting

This part works with the following brands:
  • Husqvarna
  • Jonsered
This part works with the following products:
  • Chainsaw
Part# 544047101 replaces these:
503779001, 503962401, 503962403, 503962405, 537162201, 537162204, 544047101,

Questions & Answers

?

Our customer Service team is at the ready daily to answer your part and product questions.

Be the first to ask our experts a question about this part!

Ask our Team

We have a dedicated staff with decades of collective experience in helping customers just like you purchase parts to repair their products.

Does this fit my product?

Customer Repair Instructions

All our customer repair instructions are solicited directly from other customers just like you who have purchased and replaced this exact part.

Easy

15 - 30 mins

(1 rated repair) ?
  • 1
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.

I had to replace the initiation, c.saw was not firing. While I was replacing the ignition, I replaced the pull rope, air filter and spark plug.

David from Green Cove Springs, Florida

2 of 2 people found this instruction helpful.
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers, Socket set
Parts Used:
544047101, 503818004, 501201502
Actually this was the second time into this repair. I had purchased an \"aftermarket\" ignition previously, big mistake. Another lesson learned, ALWAYS USE PROPER REPAIR PARTS. It will save a lot of time and make your repair jobs go much smoother. FYI - The saw is a Husqvarna 372, 24\" Bar

I simply removed cover that holds t he pull rope and gained access to the ignition area. Tightening down the new ignition while maintaining a gap between the ignition and the \"flywheel\", using a business card.
I used the vice grips to hold the tightened spring in place while replacing the pull rope, I find it makes it easier to replace the rope, you just have to be careful not to put too much pressure on the vice grips because the reel that holds the rope is plastic, although a very tough plastic, it\'s still plastic. Put it all back together.
Pulled the rope and was ready to start cutting. Runs like a new saw!

I have had this saw for at least 10 years, it was purchased with a group of saws at a pawn shop. I think I got at least 10 different saws for under $1,000,00. There were two of these saws in the \"package\". This one saw has been worth the amount paid for all, it is used quite a lot and with the PROPER repair parts will be used a lot more.

Thanks, I\'ll be back
Did you find this story helpful?
Thank you for voting!
  • 1

Model Cross Reference

This part works with the following models:
ERP Number: ERP9029862
Manufacturer Part Number: 544047101
Brand Model Number Description
Jonsered 2063 Chainsaw - Chain Saw
Jonsered 2063EPA Chainsaw - Chain Saw
Jonsered 2065 Chainsaw - Chain Saw
Jonsered 2065EPA Chainsaw - Chain Saw
Jonsered 2071 Chainsaw - Chain Saw
Jonsered 2071EPA Chainsaw - Chain Saw
Jonsered 2071W Chainsaw - Chain Saw
Jonsered 2163 Chainsaw - Chain Saw
Jonsered 2163EPA Chainsaw - Chain Saw
Jonsered 2165 Chainsaw - Chain Saw
Jonsered 2165EPA Chainsaw - Chain Saw
Jonsered 2171 Chainsaw - Chain Saw
Jonsered 2171EPA Chainsaw - Chain Saw
Husqvarna 356BF Leaf Blower / Vacuum - 356 Bf (20044000001-20144899999)
Husqvarna 362 Chainsaw - Chainsaw
Husqvarna 362EPA Chainsaw - Chainsaw
Husqvarna 362SPECIAL Chainsaw - Husqvarna Chainsaw Model 362SPECIAL/1999-11 (362SPECIAL/199911, 362SPECIAL/1999 11) Parts
Husqvarna 362SPECIALEPA Chainsaw - Husqvarna Chainsaw Model 362SPECIALEPA/1999-11 (362SPECIALEPA/199911, 362SPECIALEPA/1999 11) Parts
Husqvarna 362XP Chainsaw - Chainsaw
Husqvarna 362XPEPA Chainsaw - 362 Xp Epa, 19991900001-20013999999
Husqvarna 362XPSPECIAL Chainsaw - Chainsaw
Husqvarna 362XPSPECIALEPA Chainsaw - Chainsaw
Husqvarna 365 Chainsaw - Chainsaw
Husqvarna 365EPA Chainsaw - Chainsaw
Husqvarna 365H Chainsaw - Chain Saw
Husqvarna 365SP Chainsaw - Chainsaw
Husqvarna 365SPECIAL Chainsaw - Husqvarna Chainsaw Model 365SPECIAL/1999-11 (365SPECIAL/199911, 365SPECIAL/1999 11) Parts
Husqvarna 365SPECIALEPA Chainsaw - Husqvarna Chainsaw Model 365SPECIALEPA/1999-11 (365SPECIALEPA/199911, 365SPECIALEPA/1999 11) Parts
Husqvarna 371 Chainsaw - Chainsaw
Husqvarna 371EPA Chainsaw - Chainsaw
