Disassemble top of router.
Remove electronic speed control.
Split motor housing exposing top bearing.
Use a small puller to remove bearing.
Remove broken locator ring.(Used die grinder to cut mine off)
Use appropriate size socket to drive new ring into place.
Use appropriate size socket to reinstall be
... Read morearing.
Reassemble motor housing and cap.
Read less
Did you find this story helpful?
Thank you for voting!
Router would start and then shutoff after unplugging and plugging in.
Removed housing. Removed brushes and then removed armature, pulled bearing from armature and then pulled the old locator ring that was broken that is located under the bearing on amerature and replaced with new locator ring. Then replaced bearing and reassembled.
Did you find this story helpful?
Thank you for voting!
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
ERP Number: ERP19513683
Manufacturer Part Number: 2610957778
This part is in stock in our warehouse and will ship out within 1 business day of the order being placed.
New stock is on the way! On order parts usually ship within 7 business days.
Item is not in stock and usually ships 10-15 business days from the time you place your order.
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
✖
