Bosch Dummy Impact Driver Replacement Parts For Model HW-2G-SCHLAGBOH (0603241803)

We Sell Only Genuine Bosch Parts

Popular Parts for HW-2G-SCHLAGBOH

CHUCK KEY – Part Number: 2607950007 CHUCK KEY
In Stock
$10.90
END SPLICE – Part Number: 1900452012 END SPLICE
In Stock
$5.95
SCREW – Part Number: 2603490018 SCREW
Special Order
$5.95
NEEDLE BUSHING – Part Number: 1610910057 NEEDLE BUSHING
In Stock
$5.95
CARBON-BRUSH SET – Part Number: 2604321904 CARBON-BRUSH SET
In Stock
$18.88
CHEESE HEAD SCREW – Part Number: 2603410001 CHEESE HEAD SCREW
In Stock
Minimum Quantity of 2 required
$5.95
NAMEPLATE – Part Number: 160111A3H3 NAMEPLATE
Special Order
$5.95
TAPPING SCREW – Part Number: 2910611019 TAPPING SCREW
On Order
$5.95

Search Within Model

Questions & Answers for Bosch HW-2G-SCHLAGBOH
Browse all Parts Search by Area
Section 1 Diagram and Parts List for 0603241803 Bosch Impact Driver
Section 1
Previous Showing All Parts Next
Section 1
Section 1 Diagram and Parts List for 0603241803 Bosch Impact Driver
  • 1
    Housing Section – Part Number: 2605104185
    Housing Section
    Part Number: 2605104185
      No Longer Available
  • 2
    Field – Part Number: 2604220423
    Field
    Part Number: 2604220423
      No Longer Available
  • 3
    Armature – Part Number: 2604010547
    Armature
    Part Number: 2604010547
      No Longer Available
  • 4
    Switch – Part Number: 2607200084
    Switch
    Part Number: 2607200084
      No Longer Available
  • 5
    Bearing Bracket – Part Number: 2605807901
    Bearing Bracket
    Part Number: 2605807901
      No Longer Available
  • 6
    Drilling Spindle – Part Number: 2606135903
    Drilling Spindle
    Part Number: 2606135903
      No Longer Available
  • 8
    Sintered-Metal Bushing – Part Number: 2600301021
    Sintered-Metal Bushing
    Part Number: 2600301021
      No Longer Available
  • 9
    Adjusting Slide – Part Number: 2601020006
    Adjusting Slide
    Part Number: 2601020006
      No Longer Available
  • 10
    NEEDLE BUSHING – Part Number: 1610910057
    NEEDLE BUSHING
    Part Number: 1610910057
      In Stock
    $5.95
  • 11
    Bushing – Part Number: 1900301004
    Bushing
    Part Number: 1900301004
      No Longer Available
  • 13
    Grommet – Part Number: 2600707061
    Grommet
    Part Number: 2600707061
      No Longer Available
  • 13
    GROMMET DIA 6,9 MM – Part Number: 2600707059
    GROMMET DIA 6,9 MM
    Part Number: 2600707059
      Special Order
    $5.95
  • 16
    Suppression Capacitor – Part Number: 2607329095
    Suppression Capacitor
    Part Number: 2607329095
      No Longer Available
  • 17
    CARBON-BRUSH SET – Part Number: 2604321904
    CARBON-BRUSH SET
    Part Number: 2604321904
      In Stock
    $18.88
  • 21
    CONNECTING CABLE – Part Number: 2604448000
    CONNECTING CABLE
    Part Number: 2604448000
      Special Order
    $5.95
  • 22
    Suppressor Box – Part Number: 2604465030
    Suppressor Box
    Part Number: 2604465030
      No Longer Available
  • 23
    Plate – Part Number: 1601000013
    Plate
    Part Number: 1601000013
      No Longer Available
  • 24
    Plate – Part Number: 2601000018
    Plate
    Part Number: 2601000018
      No Longer Available
  • 25
    BALL – Part Number: 1903230009
    BALL
    Part Number: 1903230009
      Special Order
    $5.95
  • 26
    O-Ring – Part Number: 1610210014
    O-Ring
    Part Number: 1610210014
      No Longer Available
  • 27
    Felt Seal – Part Number: 2601020005
    Felt Seal
    Part Number: 2601020005
      No Longer Available
  • 28
    BALL 6MM – Part Number: 1903230011
    BALL 6MM
    Part Number: 1903230011
      In Stock
    $5.95
  • 29
    Intermediate Plate – Part Number: 2601000032
    Intermediate Plate
    Part Number: 2601000032
      No Longer Available
  • 32
    Reference Plate – Part Number: 2601110375
    Reference Plate
    Part Number: 2601110375
      No Longer Available
  • 33
    DAMPING PLATE – Part Number: 2601022000
    DAMPING PLATE
    Part Number: 2601022000
      Special Order
    $5.95
  • 34
    SCREW – Part Number: 2603490018
    SCREW
    Part Number: 2603490018
      Special Order
    $5.95
  • 35
    TAPPING SCREW – Part Number: 2910611019
    TAPPING SCREW
    Part Number: 2910611019
      On Order
    $5.95
  • 36
    TORX OVAL-HEAD SCREW – Part Number: 2603490026
    TORX OVAL-HEAD SCREW
    Part Number: 2603490026
      Special Order
    $5.95
  • 37
    CHEESE HEAD SCREW – Part Number: 2603410001
    CHEESE HEAD SCREW
    Part Number: 2603410001
      In Stock
    Minimum Quantity of 2 required
    $5.95
  • 38
    Chuck – Part Number: 1608571047
    Chuck
    Part Number: 1608571047
      No Longer Available
  • 38/800
    CHUCK KEY – Part Number: 2607950007
    CHUCK KEY
    Part Number: 2607950007
    ★★★★★
    ★★★★★
    (11)
      In Stock
    $10.90
  • 39
    CORD CLAMP – Part Number: 2601035001
    CORD CLAMP
    Part Number: 2601035001
      Special Order
    $5.95
  • 40
    Pressure Plate – Part Number: 2601000019
    Pressure Plate
    Part Number: 2601000019
      No Longer Available
  • 41
    Shim 14,5x21,5x0,5 Mm – Part Number: 2000101600
    Shim 14,5x21,5x0,5 Mm
    Part Number: 2000101600
      No Longer Available
  • 41
    Shim – Part Number: 2600101604
    Shim
    Part Number: 2600101604
      No Longer Available
  • 41
    Shim – Part Number: 2600101613
    Shim
    Part Number: 2600101613
      No Longer Available
  • 42
    NUT – Part Number: 2915011007
    NUT
    Part Number: 2915011007
      Special Order
    $5.95
  • 45
    SCREW – Part Number: 2912401020
    SCREW
    Part Number: 2912401020
      Special Order
    $5.95
  • 49
    Brush Holder – Part Number: 2604330016
    Brush Holder
    Part Number: 2604330016
      No Longer Available
  • 51
    Disc Spring – Part Number: 2601290014
    Disc Spring
    Part Number: 2601290014
      No Longer Available
  • 52
    Ball – Part Number: 1903230002
    Ball
    Part Number: 1903230002
      No Longer Available
  • 55
    Fan – Part Number: 2606610047
    Fan
    Part Number: 2606610047
      No Longer Available
  • 56
    END SPLICE – Part Number: 1900452012
    END SPLICE
    Part Number: 1900452012
      In Stock
    $5.95
  • 835
    POWER SUPPLY CORD EU 4,15M 2X1 – Part Number: 1607000386
    POWER SUPPLY CORD EU 4,15M 2X1
    Part Number: 1607000386
      Special Order
    $33.50
  • 888
    NAMEPLATE – Part Number: 160111A3H3
    NAMEPLATE
    Part Number: 160111A3H3
      Special Order
    $5.95
